MaxiPRO MP808BT

Based on the Android operating system, MaxiDAS MP808BT is featured with an extensive coverage of OE-level diagnostics. Installed with a fast quad-core processor, MP808BT offers maximum convenience and efficiency for your diagnosis and analysis. The intuitive user interface makes using the device effortless through a 7-inch LCD touchscreen that displays at 1024 x 600 quality.


  • image 1

• Extensive vehicle coverage for more than 80 US, Asian and European vehicle makes


• Exceptional OE-Level system coverage for all electronic systems


• Complete capabilities for codes, live data, active test, ECU information, adaptation, matching, etc.


• Smart AutoVIN technology for identifying vehicles easily


• Automatic system and software updates with real-time push message notifications via Wi-Fi


• Instant remote control tech support anytime, anywhere


• Cloud-based MaxiFix online community provides proven filed fixes


• Interactive Data Logging sessions enable direct contact with Autel Technical Support for first-hand troubleshooting of diagnostic bugs and errors


• One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized


• Convenient data management system for managing internal program applications and reviewing data


• NEW！Compatible with Videoscope and MaxiBAS BT506 to perform Battery Analysis


Operating System

Android 4.4.2

Processor

Cortex-A9 quad-core processor (1.6 GHz)

Memory

1GB RAM   & 64GB On-board Memory

Display

7-inch LCD capacitive   touchscreen with 1024x600 resolution

Connectivity

Mini USB 2.0 USB 2.0

Wi-Fi

HDMI Type A

Micro SD card slot (supports up   to 32GB)

Sensors

Light sensor for brightness   auto adjust

Audio Input/Output

Input: N/A

Output: Beep

Power and Battery

3.7 V/5000 mAh   lithium-polymer battery

Charges via 5 VDC power supply

Input Voltage

5 V/1.5 A

Operating Temp

0 to 50°C (32 to 122°F)

Storage Temp

-20 to 60°C (-4 to 140°F)

Dimensions(WXHX D)

270.8 mm (10.0”) x 176.0 mm   (6.9”) x 36.0 mm (1.4”)

Weight

885 g (2.31 lb.)

Protocols

ISO9141-2,ISO14230-2,ISO15765,K/L-Line,Flashing   Code,

SAE-J1850 VPW,SAE-J1850PWM,

ISo11898(Highspeed,Middlespeed,Lowspeed   and Singlewire CAN,fault-tolerant CAN)

SAE J2610,GM UART UART   Echo Byte Protocol

Honda Diag-H   Protocol,TP2.0,TP1.6



MaxiDAS   DS808

MaxiPRO MP808

MaxiPRO  MP808BT

MaxiPRO   MP808TS

Read Codes

√

√

√

√

Erase Codes

√

√

√

√

Live Data

√

√

√

√

ECU Information

√

√

√

√

Active Test

√

√

√

√

Service Functions

√

√

√

√

Complete OBD Diagnostics

√

√

√

√

Oil Service Reset

√

√

√

√

Parking Brake Pad Relearn After Replacement

√

√

√

√

Steering Angle Sensor Relearn

√

√

√

√

Battery Registration and Reset

√

√

√

√

Diesel Particulate Filter Regeneration

√

√

√

√

Tire Pressure Monitoring System

Basic

Basic

Basic

Complete

Immobilizer Function

Basic

Basic

Basic

Basic

Advanced TPMS Diagnostics for Complete TPMS Health Check

--

--

--

√

Activate 98% of All Known TPMS Sensors

--

--

--

√

Program AUTEL MX-Sensors

--

--

--

√

Comprehensive OBD relearn coverage

--

--

--

√

On-screen Relearn Procedure

--

--

--

√

Battery Analysis

--

--

√

√

Videoscope

√

√

√

√

Processor

Quad-core   1.6GHz

Quad-core   1.6GHz

Quad-core   1.6GHz

Quad-core   1.6GHz

OS

Android 4.4.4

Android 4.4.4

Android 4.4.4

Android 4.4.4

Memory

1G + 64G

1G + 64G

1G + 64G

1G + 64G

Display

7"   LCD

7"   LCD

7"   LCD

7"   LCD

Battery

5000 mAh

5000mAh

5000mAh

5000mAh

Internet Updatable

WiFi

WiFi

WiFi

WiFi

Multilingual Support

√

√

√

√

Historical Test Records

√

√

√

√

Save and Playback Data

√

√

√

√

Print Data via Windows PC

√

√

√

√

Vehicle communication method

Wired

Wired

Wireless   (bluetooth)

Wireless   (bluetooth)


  • Description

    • • Extensive vehicle coverage for more than 80 US, Asian and European vehicle makes


    • Exceptional OE-Level system coverage for all electronic systems


    • Complete capabilities for codes, live data, active test, ECU information, adaptation, matching, etc.


    • Smart AutoVIN technology for identifying vehicles easily


    • Automatic system and software updates with real-time push message notifications via Wi-Fi


    • Instant remote control tech support anytime, anywhere


    • Cloud-based MaxiFix online community provides proven filed fixes


    • Interactive Data Logging sessions enable direct contact with Autel Technical Support for first-hand troubleshooting of diagnostic bugs and errors


    • One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized


    • Convenient data management system for managing internal program applications and reviewing data


    • NEW！Compatible with Videoscope and MaxiBAS BT506 to perform Battery Analysis


  • Specifications

    • Operating System

    Android 4.4.2

    Processor

    Cortex-A9 quad-core processor (1.6 GHz)

    Memory

    1GB RAM   & 64GB On-board Memory

    Display

    7-inch LCD capacitive   touchscreen with 1024x600 resolution

    Connectivity

    Mini USB 2.0 USB 2.0

    Wi-Fi

    HDMI Type A

    Micro SD card slot (supports up   to 32GB)

    Sensors

    Light sensor for brightness   auto adjust

    Audio Input/Output

    Input: N/A

    Output: Beep

    Power and Battery

    3.7 V/5000 mAh   lithium-polymer battery

    Charges via 5 VDC power supply

    Input Voltage

    5 V/1.5 A

    Operating Temp

    0 to 50°C (32 to 122°F)

    Storage Temp

    -20 to 60°C (-4 to 140°F)

    Dimensions(WXHX D)

    270.8 mm (10.0”) x 176.0 mm   (6.9”) x 36.0 mm (1.4”)

    Weight

    885 g (2.31 lb.)

    Protocols

    ISO9141-2,ISO14230-2,ISO15765,K/L-Line,Flashing   Code,

    SAE-J1850 VPW,SAE-J1850PWM,

    ISo11898(Highspeed,Middlespeed,Lowspeed   and Singlewire CAN,fault-tolerant CAN)

    SAE J2610,GM UART UART   Echo Byte Protocol

    Honda Diag-H   Protocol,TP2.0,TP1.6


  • Video
  • Comparison

    • MaxiDAS   DS808

    MaxiPRO MP808

    MaxiPRO  MP808BT

    MaxiPRO   MP808TS

    Read Codes

    √

    √

    √

    √

    Erase Codes

    √

    √

    √

    √

    Live Data

    √

    √

    √

    √

    ECU Information

    √

    √

    √

    √

    Active Test

    √

    √

    √

    √

    Service Functions

    √

    √

    √

    √

    Complete OBD Diagnostics

    √

    √

    √

    √

    Oil Service Reset

    √

    √

    √

    √

    Parking Brake Pad Relearn After Replacement

    √

    √

    √

    √

    Steering Angle Sensor Relearn

    √

    √

    √

    √

    Battery Registration and Reset

    √

    √

    √

    √

    Diesel Particulate Filter Regeneration

    √

    √

    √

    √

    Tire Pressure Monitoring System

    Basic

    Basic

    Basic

    Complete

    Immobilizer Function

    Basic

    Basic

    Basic

    Basic

    Advanced TPMS Diagnostics for Complete TPMS Health Check

    --

    --

    --

    √

    Activate 98% of All Known TPMS Sensors

    --

    --

    --

    √

    Program AUTEL MX-Sensors

    --

    --

    --

    √

    Comprehensive OBD relearn coverage

    --

    --

    --

    √

    On-screen Relearn Procedure

    --

    --

    --

    √

    Battery Analysis

    --

    --

    √

    √

    Videoscope

    √

    √

    √

    √

    Processor

    Quad-core   1.6GHz

    Quad-core   1.6GHz

    Quad-core   1.6GHz

    Quad-core   1.6GHz

    OS

    Android 4.4.4

    Android 4.4.4

    Android 4.4.4

    Android 4.4.4

    Memory

    1G + 64G

    1G + 64G

    1G + 64G

    1G + 64G

    Display

    7"   LCD

    7"   LCD

    7"   LCD

    7"   LCD

    Battery

    5000 mAh

    5000mAh

    5000mAh

    5000mAh

    Internet Updatable

    WiFi

    WiFi

    WiFi

    WiFi

    Multilingual Support

    √

    √

    √

    √

    Historical Test Records

    √

    √

    √

    √

    Save and Playback Data

    √

    √

    √

    √

    Print Data via Windows PC

    √

    √

    √

    √

    Vehicle communication method

    Wired

    Wired

    Wireless   (bluetooth)

    Wireless   (bluetooth)
